Plywood Boat Building Blog

This blog will take you along the different steps of building a 23 foot dropkeel sailboat. The DIDI 23 is one of the available designs for the amateur builder designed by Dudley Dix. The boat is built as a radius chine trailer sailer from plywood with bulb dropkeel.

ABOUT ME
I am 64, married, have two adult children and working as engineer for rf techniques at a physical research centre of the Helmholtz Association. I live close to the Elbe river in a suburb of Hamburg, Germany.

Saturday, 28 July 2018

Launching

Working time been invested: 2940 hours

Tuesday, 24 July 2018

Mounting the Bulb Slabs, Part II

Two out of the six M16x1 S/S-bolts are to short for screwing on a nut.

Special nut, machined from 20 mm diameter brass-rod and a reamed M14-nut

The brass-rod has been soldered into the reamed M14-nut

The 3 mm thick washer should distribute the pressure to the lead

All nuts tightened to a torque of 25 Nm

Sunday, 15 July 2018

Mounting the Bulb Slabs, Part I

Friday, 13 July 2018

Inserting the Keel Foil into the Shaft
